H51100RC

Name: H51100RC Model:

Applicable scope:

Product details

Features of LiFePO4 Battery

● Longer Cycle Life: Offers up to 10 times longer cycle life and 5 times longer float/calendar life than lead acid battery,helping to minimize replacement cost and reduce total cost of ownership.

● Lighter Weight: About 40% of the weight of a comparable lead acid battery,A ”drop in” replacement for lead acid battery.

● Higher Power: Delivers twice power of lead acid battery,even high discharge rate,while maintain high energy capacity.

● Wider Temperature Range: -10℃~55℃.

● Superior Safety: Lithium iron phosphate chemistry eliminates the risk of explosion or combustion due to high

 impact,over charging or short circuit situation.

● No Memory Effect: Support unstable partial state of charge(UPSOC) (charge/discharge) utilization.

Functions of Battery

● OVP,UVP,OTP,OCP,SCP.

● Self-management on charging and discharging,single cell  balancing function.

● Supports communication with mainstream inverters over RS485/CAN.

● Intelligent design,supports battery upgrade over RS232 software

● Colorful LCD,displays battery information

Qualifications

● 20 years professional experience on lithium ion battery power designing, manufacturing, sales

● Passed ISO9001, ISO14001, ISO45001, UL1642, CE,ROHS, IEC62619, IEC62620, UN38.3

● Battery cell cost advantage


General Data
Nominal Voltage51.2V
Nominal Capacity100Ah
Energ5120Wh
Internal Resistance(ACR)≤100mΩ(without BMS)
Cycle Life≥5000 cycles@70%DOD
Design Life≥10 years@25℃
Self-Discharge(30days)≤5% @25℃
Efficiency of Charge≥98%
Efficiency of Discharge

≥100% @ 0.2C

≥96% @1C
Charge Voltage
56-57.6V
Charge Mode
0.2C to 57.6V, then 57.6V charge current to 0.02C (CC/CV)
Max.Continuous Charge Current
100A
Max.Continuous Discharge Current
100A
Discharge Cut-off Voltage
≤45V±0.5V
Water Dust Resistance
IP20
CaseIron(Insulation painting)
Dimensions(W*D*H) (excluding hanger and handlebar)442*450*157mm
Max.Weight
≤45kg
Min.Gravimetric Specificen ergy≥113Wh/kg
Parallel in maximum15pcs,depends on the installation condition
Operating Environment
Charge Temperature Range
0℃~60℃
Discharge Temperature Range-10℃~60℃
Optimum Operation Temperature10℃~35℃
Storage Temperature

-20℃~55℃
≤85% Relative Humidity
General Functions
Parallel Communication
2*RS485
Battery with Equipment
1*RS485/1*CAN
Battery De bugging Communication
1*RS232
Dry Contact

PIN1 to PIN2:Normally open,closed during low power

PIN3 to PIN4:Normally open,closed during fault protection

SOC Light
6 * LED
Charge Current limitWhen the charging current exceeds the set value,turn on the current limit and limit the current to 20A
Optional Functions
LCD ScreenYes Displays the total voltage pack, cell voltage, temperature, BMS status,etc
No
Gyroscopeanti-theft
Yes
Keep the vibration for more than 1 minutes to turn on anti-theft
No
BuzzerYes  No
