| Features of 1kVA UPS | Functions of 1kVA UPS |
● Line-interactive design and true sine wave output ● Microprocessor control guarantees high reliability ● Built-in Boost and Buck AVR to stabilize input voltage ● User-Replaceable hot swappable battery design & Cold startup capability ● Combo solution of UPS+battery, smart design ● Built-in LiFePO4 battery with big advantages ● High volume: 2kWh battery capacity, can max support 3h use at rated power ● Fast charging: Charge the battery fully within 5h ● Longer cycle: 10 times of the VRLA battery, with design life 10 years. Capable to work at 100% DOD ● Lighter weight: Delivers 3 times energy than VRLA battery with the same weight ● Higher safety: Use lithium iron phosphate chemistry with high safety and reliability | ● Fully protection for overload, short circuit, overheat and battery over discharge protection ● Flexible AC input voltage with AC115V or AC230V ● Flexible AC output voltage with AC100-127V or AC200- 253V ● Efficient thermal management with fan ● Colorful LED, displays system state. Qualifications ● 20 years professional experience on lithium-ion battery power designing, manufacturing, sales ● Passed ISO9001, ISO14001, ISO45001, UL1642, CE, ROHS, IEC62619, IEC62620, UN38.3 ● Battery cell cost advantage |
| Model | 1kVA UPS | |
| Overview | Nominal Capacity | 1000VA |
| Power Factor | 0.7 | |
| Rated Power | 700W | |
| Waveform | Pure sine wave | |
| Input | Nominal Voltage | 115 / 230V |
| Voltage Range | 72-144V / 145-275V | |
| Frequency Range | 60Hz&115V/50Hz&230 | |
| Output | Nominal Voltage | 115V/230V |
| Voltage Range (AC Mode) | 100-127V/200-253V（﹢10%~-13%） | |
| Voltage Range(Batt.Mode) | 115/230V±6% | |
| Frequency Range | 50/60Hz | |
| Power Transfer Time | ＜4ms(Typical) | |
| Overload | Protection (AC Mode) | 100%-120% 1min |
| Protection (Batt. Mode) | 100%-120% 25s,＞120% UPS Off at onc | |
| Display | LED | 4 LEDs |
| LED Status | AC mode, Battery mode, Standby mode, Faulty | |
| Environment | Application | Indoor use |
| Temperature | 0-45℃ | |
| Humidity | 3000 Meters max Elevation 10-95% | |
| Built-in Battery | Battery Chemistry | LiFePO4 |
| Voltage | 25.6V | |
| Capacity | 80Ah | |
| Charge Current | ＞15A | |
| Full Load Backup Time | ~180 min | |
| Cycle Life | More than 3000 times @ 80% DOD | |
| BMS | Built-in smart BMS with OVP、UVP、OCP、SCP、OTP、UTP and etc | |
| Physical | Dimension(L*W*H) | 400*330*293mm（Accessories not included） |
| Net Weight | ＜32.4Kg | |
| Design Life | 10 years for battery & UPS circuit |
